Connections in GraphQL

To enable pagination, GraphQL utilizes a cursor-based system known as Connections. As outlined in the specification, the default connection should at least implement the following structure:

• Edges: These represent the actual data nodes in the connection. Each edge contains a cursor that points to the corresponding data item.
• Nodes: The actual data objects within each edge. These nodes contain the relevant information associated with the particular data item.
• Page Info: This provides information about the pagination, such as the existence of previous and next pages.

The specification states that each of the above can be extended with additional fields as the schema designer deems necessary. If you're interested in learning how to do this, continue reading.

An example GraphQL application

Let’s use this simple has_many :through association as an example

The GraphQL code could look like this:

# app/graphql/types/query_type.rb
module Types
  class QueryType < Types::BaseObject
    field :student, StudentType, null: true do
      argument :id, ID, required: true
    end

    def student(id:)
      ::Student.find(id)
    end
end

# app/graphql/types/student_type.rb
module Types
  class StudentType < BaseObject
    field :id, ID, null: false
    field :name, String
    field :courses, CourseType.connection_type, null: false
  end
end

# app/graphql/types/course_type.rb
module Types
  class CourseType < BaseObject
    field :id, ID, null: false
    field :title, String
  end
end

A query with all fields required by GraphQL specification would look like this:

query {
  student(id: 1) {
    id
    name
    courses(first: 10) {
      edges {
        cursor
        node {
          id
          title
        }
      }
      pageInfo {
        hasNextPage
        hasPreviousPage
        startCursor
        endCursor
      }
    }
  }
}

Exposing information from the join table

The enrollment join table contains the field enrollment_date that should be exposed in a query. According to the GraphQL-Ruby docs:

Edges can reveal (…) information about the relationship.

However, the documentation does not provide an example of how to do it. But don't worry, you can accomplish this in these 4 steps:

1. Create a Custom Connection Type class and:

   • register a custom Edge class,
   • define the nodes method (resolver method for default field).


   # app/graphql/types/enrollment_connection.rb
   module Types
     class EnrollmentConnection < BaseConnection
       # register a custom Edge class
       edge_type(EnrollmentEdge)

       # This method is required for 'nodes' shorthand to work
       def nodes
         # object is GraphQL::Pagination wrapper for ActiveRecord::AssociationRelation
         object.edge_nodes.map(&:course)
       end
     end
   end



2. Create a Custom Edge Type class and:

   • register a Node class,
   • define of fields to expose,
   • define resolver methods for defined fields,
   • define a node method (resolver method for default field).


   # app/graphql/types/enrollment_edge.rb
   module Types
     class EnrollmentEdge < BaseEdge
       # register a Node class
       node_type(Types::CourseType)

       # define field and resolver
       field :enrollment_date, GraphQL::Types::ISO8601Date, null: true

       def enrollment_date
         # object.node is an instance of Enrollment class
         object.node.enrollment_date
       end

       # point node method to the associated course
       def node
         object.node.course
       end
     end
   end



3. Register a custom Connection field on a Student Type


   # app/graphql/types/student_type.rb
   module Types
     class StudentType < BaseObject
       field :id, ID, null: false
       field :name, String
       # connection is inferred from the type's name ending in *Connection
       field :courses, EnrollmentConnection

       def courses
         object.enrollments.includes(:course)
       end
     end
   end



4. Include enrollmentDate in the query


   query {
     student(id: 1) {
       id
       name
       courses(first: 10) {
         edges {
           cursor
           enrollmentDate  # <--------- here
           node {
             id
             title
           }
         }
       }
     }
   }



That was easy!

Remark: Please be cautious of the N+1 issue that can be easily introduced here. Instead of using includes(:course), consider using GraphQL::Dataloader to batch-load tags from EnrollmentEdge#node, or you can also explore the ar_lazy_preload gem for automagic preloading.

Showing the number of records

With the above structure, we can easily paginate by passing the cursor to the after argument until we reach the endCursor or until hasNextPage returns false.

However, in this implementation, there is no way to determine the total number of pages or records.

To address this, modify the EnrollmentConnection class. However, since this is a common requirement for accessing data, you can also add it to your BaseConnection. Let's add a recordCount field and a resolver.

# app/graphql/types/base_connection.rb
module Types
  class BaseConnection < Types::BaseObject
    include GraphQL::Types::Relay::ConnectionBehaviors

    field :record_count, Integer

    def record_count
      object.items.size
    end
  end
end

Now add it to the query:

query {
  student(id: 1) {
    id
    name
    courses(first: 10) {
      recordCount  # <--------- here
      edges {
        cursor
        enrollmentDate
        node {
          id
          title
        }
      }
    }
  }
}

If you need, you can extend other parts of a Connection like pageInfo in a similar fashion. Here is the repository with the app used in the examples. Feel free to experiment with it. Be sure to check out branches other than 'main' as well.
